224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯发电厂用打火机气油资金性好: 高级的气油管控程序，具有的STC、ESTC 分级管理管控程序，比较特殊定制的汽缸表层一氧化碳点燃仓，直流电喷射出气油，加以地吸雾，一氧化碳点燃加以地。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电厂用打着机瞬态机械性能比较好: 完美无瑕的打着机整体结构设计，听取康明斯独一无二的EFC软件系统，抑制误差高，卡死用时快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯带发电用热车机升额定功率高: 大体设计宽敞.形态布设适当合理，运作保持稳定。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷车型 QSNT. QSK19. QSK38. QSK50具备我国非村道第三步价段及南美Tier2. Tier 3排污标准耍求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备件管理应得性好， 启主观因素使用及维护皮肤保养方便快捷，人工成本费用低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

瓦数超范围 Power Range   224-310KW形式 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L形状面积 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净质理 Dry Weight   940kg

224-310KW康明斯发电厂用热车机的优点：质量分数小， 压缩成比低， 网格板气体微波加热，适于加载，位移车载影音24v电源的优先选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

起倾向规格型号	长用额定功率(kW)Prime Power	备用电源公率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
